SSFD-100 fruit freeze dryer

The SSFD-100 model of fruit freeze dryer can handle between 100kg to 150kg of fruit material per batch, with a shelf area of 10 square meters, meeting the requirements of small-scale production for small enterprises.

This model of freeze-dryer can process a wide range of fruit varieties, including apples, bananas, strawberries, blueberries, cherries, grapes, pineapples, oranges, lemons, mangoes, kiwis, litchis, etc.

The integrated compact design of this equipment helps to save on transportation and installation costs.

Contact Us

分类:

SSFD-100 freeze dry machine (freeze-drying area: 10m2) (quick freezing freeze-drying integrated model) SSFD-100 is one of the best-selling models in small freeze-drying equipment. This freeze dry machine has a remote terminal system that can be viewed and operated simultaneously on both PC and mobile devices. The shelf area of SSFD-100 is 10m2, suitable for handling fresh materials ranging from 100kg to 150kg per day. Both conductive and radiative SSFD-100 freeze-drying equipment are available for sale. And there is a lot of semi-finished product inventory in the warehouse, which can be delivered quickly. This model of machine is very suitable for startups. The production capacity is much higher than that of experimental models, and it is used for small-scale production to develop the market. The SSFD-100 freeze dry machine is an integrated compact design. This design and type of freeze-drying equipment help save transportation and installation costs. Once the machine is received and powered on, it can be used. All you need to do is connect the three-phase electricity on the panel to the electrical panel of the machine. The air-cooled condenser is a standard configuration for SSFD-100 and all smaller models. If you need a water-cooled condenser in a hot place, it is optional and technologically mature. The SSFD-100 freeze-drying equipment consists of a chamber, an air-cooled condenser, vacuum, refilling, circulation, heating, control system, and a complete set of product trays. This device has EU CE certification.





 specifications model

SSFD-100

Freeze dried area(m2)

10m2

Tray area(m2)

10m2

Loading capacity(kg)

50kg

Water supplement capacity of cold well(kg)

200kg

External dimensions(L* W * H mm)

4500×1600×2100mm

Plate layer temperature(℃)

-50~120℃

Cold well temperature(℃)

-70℃

Vacuum degree in the chamber(pa))

3pa

Heating method

Silicone oil heating/10CS

Industrial control host brand

Siemens PLC

Installed power

36KW

Equipment weight

4500kg



Application display

About us

SHENSHENGThe company is located in Zhenglu Industrial Park, Tianning District, Changzhou City. It is a drying technology enterprise that integrates research and development, design, production, sales, and service. The company independently produces and sells freeze-drying machines, vacuum freeze-drying machines, pharmaceutical equipment, food equipment, and various production lines; Research and development of automation systems.

FAQ

Q:What is the working principle of freeze dryers ?

A:Freeze dryers remove moisture from wet liquids or solids by freezing them and then subjecting them to a vacuum environment. This process transforms the material into a dry powder or solid, extending its shelf life and stability.

Q:How do I choose the right freeze dryer model for my needs ?
A:Selecting a model depends on factors such as vour application, sample volume, freezing capacity. temperature control reguirements. and more. Our experts can provide customized recommendations.

Q:What are the key maintenance and care steps for freeze dryers ?

A:Maintenance involves regular cleaning, temperature control calibration, and replacing consumables like silicone gaskets to ensure the smooth operation of the freeze dryer.

Q:How can Iontimize the freeze-drving process to improve efficiency ?
A:Optimizing the process includes sample pretreatment. setting appropriate temperature and vacuur conditions. and monitoring the freeze-drving process to achieve the best results.
